BT40 Series

BT40#

Outline Drawing

renishaw-acu250-r-asis-corrected
renishaw-acu250-r-asis-corrected
renishaw-acu250-r-asis-corrected

Video

video-a402

ContRoller-Types

Part Number 42DEXG009A (BT-40 Sensor Motor AIS)-Magazine on the left side
(T to T)Duration 1.3~1.5sec(3~5kg)
Tool Buckling Angles 60°~90°(based on customer requirements)
Cutter Pulling Strokechange 115mm-MAX(We can customize strokes according to different types of tool holders)
Maximum Loading 7kg (Please contact the DEX sales team for more details)
Signal Specifications Decoder
Driving Horse Power 1HP
Weight Of The Product 115kg
Accuracy

Overlapping accuracy 4"

Horizontal Accuracy 0.2mm
Characteristics

AIS Smart Control is equipped with multiple control modes, achieving greater flexibility.

Sensor motor can be integrated for tool magazine controlling.

A single drive controls both, the ATC and the magazine.

Movement Timing Illustration



size-drawings-acu250-en-01

Angle for cutter change can be defined per customer's need (60°~ 90°)

top-view-drawing-acu250-02

We can customize strokes according to different types of tool holders

A402 Instant Loading Diagram

Tool Change Arm T-to-T Distance/ Tool Arm Weight Reference
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
6Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
7Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
6Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
7Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
6Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
7Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
6Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
7Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
6Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
7Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
Tool Change Arm T-to-T Distance/ Tool Arm Weight Reference
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
6Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
7Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:7 1.14 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
6Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
7Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
6Kg*2 50Hz 1:7 1.36 sec
60Hz 1:9 1.47 sec
7Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
5Kg*2 50Hz 1:7 1.36 sec
60Hz 1:8 1.31 sec
6Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
7Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:9 1.47 sec
5Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
6Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
7Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
Tool Change Arm T-to-T Distance/ Tool Arm Weight Reference
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:7 1.36 sec
60Hz 1:9 1.47 sec
5Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
6Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
7Kg*2 50Hz 1:8 1.55 sec
60Hz 1:10 1.64 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
5Kg*2 50Hz 1:8 1.55 sec
60Hz 1:9 1.47 sec
6Kg*2 50Hz 1:9 1.75 sec
60Hz 1:10 1.64 sec
7Kg*2 50Hz 1:9 1.75 sec
60Hz 1:10 1.64 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:8 1.55 sec
60Hz 1:10 1.64 sec
5Kg*2 50Hz 1:9 1.75 sec
60Hz 1:10 1.64 sec
6Kg*2 50Hz 1:9 1.75 sec
60Hz 1:12 1.96 sec
7Kg*2 50Hz 1:10 1.94 sec
60Hz 1:12 1.96 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:9 1.75 sec
60Hz 1:12 1.96 sec
5Kg*2 50Hz 1:10 1.94 sec
60Hz 1:12 1.96 sec
6Kg*2 50Hz 1:10 1.94 sec
60Hz 1:12 1.96 sec
7Kg*2 50Hz 1:12 2.33 sec
60Hz 1:15 2.45 sec
Tool Weight
Bilateral Loading of Tools		 Motor Frequency Compatible with
3/4HP motors		 ATC Time Interval
For Cutter
4Kg*2 50Hz 1:10 1.94 sec
60Hz 1:12 1.96 sec
5Kg*2 50Hz 1:12 2.33 sec
60Hz 1:12 1.96 sec
6Kg*2 50Hz 1:12 2.33 sec
60Hz 1:15 2.45 sec
7Kg*2 50Hz 1:12 2.33 sec
60Hz 1:15 2.45 sec
