ATC Systems

BT50 Series

BT50# Strehgth-type

Outline Drawing

renishaw-acu250-r-asis-corrected

Video

video-a504-250208

ContRoller-Types

AIS

Part Number	54DEXA104A (BT-50)-Horizontal
Time Interval For Cutter	Please refer to the A504 speed ratio loading table
Tool Buckling Angles	60°~90°(based on customer requirements)
Cutter Pulling Strokechange	165mm-MAX(We can customize strokes according to different types of tool holders)
Maximum Loading	25kg
Signal Specifications	Proximity Switch PNP-NOx3~4
Driving Horse Power	1.5HP~2HP
Weight Of The Product	215kg
Accuracy	Overlapping accuracy 3" Horizontal Accuracy 0.2mm

Movement Timing Illustration

size-drawings-acu250-en-01

Angle for cutter change can be defined per customer's need (60°~ 90°)

top-view-drawing-acu250-02

We can customize strokes according to different types of tool holders
